#17-8147
Air bag removal set

- for disassembling the air bag unit
- suitable for following car types:
- VW Bora, Golf, Jetta, Lupo, New Beetle, Passat, Polo
- Audi A4, A6
- BMW, Mecedes-Benz, Opel, Renault: all types
- Seat: all types built in or after 1999
- Scoda Fabia, Oktavia, Superb
- incl. 2 special T-30 Bits (tamperproof and non-tamperproof)

#17-8306

VW subframe locating dowels

- for precisely aligned mounting of the subframe
- needed e.g. for replacing the rubber bushings
and all jobs for which the auxiliary frame (subframe)
is removed
- suitable for:
VW Scirocco (09), EOS (06), Golf (09), Golf Plus (05), Jetta (04-06),
Polo (02), Fox (06), Passat (06), Passat CL (09), Audi A3 (04)
and Audi A3 (04), TT (07), A4 (01)
- to be used as OEM T10096

#17-8555

VAG crankshaft turning tool

- facilitates turning the crankshaft for e.g.
checking the engine timing
- suitable for Audi A6 2005>, Audi A8 2003>
with 6- and 8-cyl. engines
2.4 L, 3.2 L FSI, 6 - and 8-cyl. TDI Common Rail
- to be used as OEM T40058

#17-8565

VAG Cam turning tool set

- used for removal and installation of 4/3-way
central valve on the camshaft adjustment
- suitable for VW Passat, Audi A3, A4, A5, Q5 1.8l
and 2.0 liter engines with chain drive
- to be used as OEM T10352 / T10352/1

#17-9000

VAG Cartridge oil filter drain adapter

- suitable for VAG 1.8 and 2.0L gasoline engines
   with engine codes AXW - BLX - BLR - BLY - BVX -
   BVY - BVZ
   Audi A3 / A4 / A6 / DD
   VW Golf V - Passat - Touran - New Beetle - EOS -
   Jetta III - Seat Altea - Leon - Octavia - Toledo
- opens a valve when screwing in the oil filter housing
- allows a controlled and clean oil discharge
from the oil filter housing

#17-1002

0AM clutch assembly/removal spoon

Used to operate the engaging lever during dismantling and mounting of the mechatronic unit on 7-speed dual clutch gearbox 0AM.
Type/Model: Golf 2004>, Golf 2009>, Audi A3 2004>, Eos 2006, Passat 2006>, Passat CC 2009>.

#17-9991

Transmission Oil filler pump & adapters

- for filling gearboxes and differentials with oil
- new version with second hose for backflow of
excessive oil
- with 8-pc adaptor set with different angles and
thread types
- ideal for filling Mercedes 722.9,
VW / Audi DSG and CVT transmissions
- hose length 160 cm
- can be used up to SAE 140

#17-9991-2

Spare bottle

- One bottle for every fluid type

#17-62625

4-piece Engine Timing Tool Kit for VAG FSI / TSI 1,4 & 1,6 l with Timing Chain

- to check and adjust camshaft timing
- required when replacing timing chains
- suitable for VAG FSI and TFSI 1.4L and 1.6L engines
- contains following tools:
- camshaft locking tool, to be used as OEM T10171
- setting gauge holder, to be used as OEM T10170
- crankshaft locking tool, to be used as OEM T10340
- tensioner locking tool, to be used as OEM T40011
- fits for following models / engines
- Audi A3 (03-10),
- Seat Ibiza , Leon, Altea
- Skoda Octavia (04-09), Fabia (07-09), Superb (09-10), Roomster (06-09)
- VW Golf (03-09), Golf Plus (05-09), Jetta (06-09), Passat (05-09),
Polo (02-08), Scirocco (09-10), Tiguan (07-09), Touran (03-09), Eos (06-09)
- engine code: AXU, BLG, BAG, BMY, BKG, BMK, BLF, CAVA, BLN, CAVB, BLP,
CAVC, CAVE, CAVF, CAVD, CAXA, CAXC, CDGA, BTS

#17-62640

3-piece Crankshaft Timing Belt Pulley Locking Tool Set

- for VAG 2.0 liter TDI and some 1,9L TDI
with oval crankshaft wheel
use as OEM T10100
- includes:
   - crankshaft locking Tool
     to be used as OEM T10100
   - locking bolt for pump
     to be used as OEM 3359
   - locking plate for idler
     to be used as OEM T10008

#17-62641

3-piece Crankshaft Timing Belt Pulley Locking Tool Set

- for VAG 1.2 - 1.4 - 1.9l TDI engines
with round crankshaft wheel
- includes:
   - crankshaft locking Tool
     to be used as OEM T10050
   - locking bolt for pump
     to be used as OEM 3359
   - locking plate for idler
     to be used as OEM T10008

#17-8155

VAG Engine Timing Tool Kit

- suitable for following engines:
1.9/2.0 ltr. unit injector drive
1.9 ltr. TDI (normal diesel)
2.5 ltr. V6-TDI (no gasoline)
3.3 ltr. V8-TDI (no gasoline)
1.2 ltr. 3-cylinder and 1.4/1.6 ltr. gasoline engine
- contains important adjustment tools such as:
setting gauge for camshaft (e.g. VW 1.9 l. TDI)
- locking tool for timing belt
(e.g. VW / Skoda 1,9 l / 2.0 l TDI pump/nozzle)
- camshaft locking tool
(e.g. VW / Audi 2.5 l V6 TDI)
- adjustable tensioner wrench
(universal for VW / Audi)
- injection pump locking pin
(e.g. VW / Audi / Seat / Skoda)
- mounting plate for timing belt tensioner
(VW / Skoda 4 cyl. TDI pump/nozzle)
- 22 mm open socket
for diesel injectors
- camshaft setting tools, to be used as OEM
T10123, T10120, 3458, 3418, 2065A, 3366, T10098 / 3418
- crankshaft setting tools, to be used as OEM
T10121, 3242, T10050, T10100
- tensioner pulley locking pins, to be used as OEM
T10060A, T10020, T10008, T40011
- injection pump locking tools, to be used as OEM
3359, 2064

#17-8219

VAG Engine Timing Tool Kit

- suitable for following engines:
1.9/2.0 ltr. unit injector drive
1.9 ltr. TDI (normal diesel)
2.5 ltr. V6-TDI (no gasoline)
3.3 ltr. V8-TDI (no gasoline)
1.2 ltr. 3-cylinder and 1.4/1.6 ltr. gasoline engine
- contains important adjustment tools such as:
setting gauge for camshaft (e.g. VW 1.9 l. TDI)
- locking tool for timing belt
(e.g. VW / Skoda 1,9 l / 2.0 l TDI pump/nozzle)
- camshaft locking tool
(e.g. VW / Audi 2.5 l V6 TDI)
- adjustable tensioner wrench
(universal for VW / Audi)
- injection pump locking pin
(e.g. VW / Audi / Seat / Skoda)
- mounting plate for timing belt tensioner
(VW / Skoda 4 cyl. TDI pump/nozzle)
- 22 mm open socket
for diesel injectors
- camshaft setting tools, to be used as OEM
T10123, T10120, 3458, 3418, 2065A, 3366, T10098 / 3418
- crankshaft setting tools, to be used as OEM
T10121, 3242, T10050, T10100
- tensioner pulley locking pins, to be used as OEM
T10060A, T10020, T10008, T40011
- injection pump locking tools, to be used as OEM
3359, 2064
